TM 300
TM 300 is all-round, top of the line device for wires and wire harnesses taping. Its programmed interface allows to process virtually every harness or cable. And its easy to change production batch in seconds.
It is a fully programmable, fully automatic belt-driven feed machine with a linear grip that guarantees highest operational safety. Reinforced structure, powerful components guarantee the implementation of taping tasks even in most difficult applications.
It is equipped with user-friendly HMI, many innovative, safe and helpful solutions and above all else fully configurable.
Technické parametry
| Název | Hodnota |
|---|---|
| Napájení | 230V/16A , compressed air 6 bar. |
| Rozměry | 1265 x 700 x 1300-1700(max.height) mm |
| Otáčky | 0 – 1200 rpm; stepless control, max rotation speed can be set independently. |
| Průměr svazku | max. 20 mm (optional 35 mm) |
| Použití | taping of wires, simple or complex and long wire harnesses and other materials |
| Hmotnost | 285 kg |
| Šíře pásky | 9 – 19 mm |
| Materiál pásky | all available machine tapes |
